| Business Type | Supplier, Trader |
| Type | Power Regulator |
| Operating Temperature | 0-40°C |
| Voltage Power Supply | 480V & 600V Max |
| Click to view more | |
Product Details
Auxiliary Power Supply
110V / 220V / 415V AC
Fan Voltage Supply
230V ±15% As Standard, 110V On Request
Digital Input
Two Optoisolated Digital Input (12/24V DC) For Various Functions
Firing
Burst Firing Up To 255 Burst / Zero Cross Over Firing
Control Feedback Mode
V/ V2/ I/ I2/ Vxl
REVO I is a high reliability universal power regulator that has an advanced microprocessor that makes it universal and completely configurable via software. 2PH from 100A to 700A, 3PH from 100A to 500A.
Technical Specification
- Operating Temperature: 0-40°
- Voltage Power Supply: 480V & 600V Max.
- Auxiliary Power Supply: 110V / 220V / 415V AC
- Fan Voltage supply: 230V ±15% as a standard and 110V on request
- Analog Input 1: Primary reference - Current Input 0-20mA / 4-20mA - Voltage Input 0-10V - Potentiometer Input 10K Ohm min
- Analog Input 2: External feedback, Setpoint
- Digital Input: Two optoisolated digital input (12/24V DC), for Enable, SP AI1/ AI2, local / remote, heater bakeout, Alarm reset
- Alarm Digital Output: Heater Break, Short circuit, SCR over temperature, watchdog - Relay Output
- Firing: Burst firing up to 255 Burst / Zero Cross over firing
- Control Feedback Mode: V/ V2/ I/ I2/ Vxl
- Fuses: High speed Semiconductor fuses fitted Internally
- Mounting: Panel mounting
- Protection: IP20
